Images are for reference only. See Product Specifications for product details
CTS Electrocomponents 219-4MSTJRF
SWITCH SLIDE DIP SPST 100MA 20V
- Manufacturer
- CTS Electrocomponents
- Datasheet
- Price
- 0.62
- Stock
- 0
Product Details
- Features
- Epoxy Sealed Terminals
- Contact Material
- Beryllium Copper
- Washable
- No
- Termination Style
- PC Pin
- Packaging
- Tube
- Height Above Board
- 0.190" (4.83mm)
- Part Status
- Active
- Number of Positions
- 7
- Actuator Type
- Slide (Standard)
- Current Rating (Amps)
- 100mA
- Body Material
- -
- Operating Temperature
- -40°C ~ 85°C
- Mounting Type
- Through Hole
- Actuator Level
- Raised
- Pitch
- 0.100" (2.54mm), Full
- Contact Finish
- Gold
- Length
- 0.758" (19.25mm)
- Voltage Rating
- 20VDC
- Series
- 209
- Electrical Life
- 2,000 Cycles
- Circuit
- SPST
- Mechanical Life
- -
