Images are for reference only. See Product Specifications for product details
Mechatronics Fan Group F6025E12B-FHR-EM3
FAN AXIAL 60X25MM 12VDC WIRE
- Manufacturer
- Mechatronics Fan Group
- Datasheet
- Price
- 13.57
- Stock
- 8
Product Details
- Part Status
- Active
- Operating Temperature
- -
- Termination
- 2 Wire Leads
- Bearing Type
- Ball
- RPM
- 5800 RPM
- Voltage Range
- -
- Noise
- 42.0 dB(A)
- Static Pressure
- 0.370 in H2O (92.2 Pa)
- Width
- 25.00mm
- Voltage - Rated
- 24VDC
- Series
- F6025-H
- Lifetime @ Temp.
- -
- Weight
- 0.139 lb (63.05 g)
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Air Flow
- 28.0 CFM (0.784m³/min)
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Size / Dimension
- Square - 60mm L x 60mm H
- Features
- Conformal Coating, Thermal Overload Protector (TOP)
- Ingress Protection
- -
- Approvals
- CE, cUL, TUV, UL
- Current Rating (Amps)
- 0.170A
