PTC Resettable Fuses

PTC Resettable Fuses are designed to stop current flow when it exceeds a certain limit (overcurrent protection). The Fuses work by increasing its resistance as its temperature rises due to the current increase. The trip current ranges from 14 mA to 50 A with the Time to trip ranging from 8 ms to 90 s. PTC = Positive Temperature Coefficient.

---

EPCOS (TDK) B59735T1120A062

THERMISTOR PTC 35 OHM 15% 4SMD

1.57

EPCOS (TDK) B59750T1120A062

THERMISTOR PTC 50 OHM 15% 4SMD

0.74

EPCOS (TDK) B59315P1080A062

THERMISTOR PTC 25% 4032

1.95

EPCOS (TDK) B59215P1120A062

THERMISTOR PTC 25 OHM 25% 2SMD

1.82

EPCOS (TDK) B59835T1120A062

THERMISTOR PTC 35 OHM 15% 4SMD

1.83

EPCOS (TDK) B59623A0090A062

THERMISTOR PTC 470 OHM 25% 0603

1.1

EPCOS (TDK) B59622A0090A062

THERMISTOR PTC 220 OHM 25% 0603

1.1

Vishay BC Components PTCCL11H361FBE

THERMISTOR PTC 5.3 OHM 20% RAD

0.66
