Trimmer Potentiometers

Trimmer potentiometers allow for precise manual adjustment of an in-circuit resistance value. Also known as trimpots, they are available in bottom, side or top adjustment and may allow for single or multiple turns of actuation. They range in value from 10 Ω to 5 MΩ of resistance and 5% to 30% of value tolerance in surface mount, through-hole, chassis mount, and panel mount configurations.

---

Panasonic Electronic Components EVM-3RSX50B53

TRIMMER 5K OHM 0.15W J LEAD BACK

0

Bourns, Inc. 3361P-1-253GLF

TRIMMER 25K OHM 0.5W GW TOP ADJ

0

TE Connectivity Passive Product 3142W501P

TRIMMER 500 OHM 0.15W J LEAD TOP

0.76

TE Connectivity Passive Product 3142W203P

TRIMMER 20K OHM 0.15W J LEAD TOP

0

Vishay / Sfernice TS53YL103MR10

TRIMMER 10K OHM 0.25W GW TOP ADJ

1.8

Bourns, Inc. 3314J-2-504E

TRIMMER 500KOHM 0.25W J LEAD TOP

2.18

Bourns, Inc. 3314G-1-103E

TRIMMER 10K OHM 0.25W GW TOP ADJ

0

Bourns, Inc. PVG5H201C03R00

TRIMMER 200OHM 0.25W J LEAD SIDE

1.67
