Scale Dials

Scale Dials are a removable device with a face that is marked in predefined units to indicate the degree that a shaft has been turned. The knobs have a shaft size of 0.125” (3.18 mm), 0.236” (6.00 mm), or 0.250” (6.35 mm) with the number of turns being 1, 10, 11, 15, 20, 21, 30, or 100.

---

Littelfuse Inc. P0400-82

FACE PLATE 0.1-10 SEC. REV. H

4.82

Littelfuse Inc. P0400-27

FACE PLATE 0-10 DIAL REV A

2.91

Littelfuse Inc. P0400-17

FACE PLATE 1-30 SEC. REV. E

2.11

Bourns, Inc. H-23-6M

DIAL SCALE 15 TURN CONCENTRIC

12.28

Bourns, Inc. H-22-6M

DIAL SCALE 15 TURN CONCENTRIC

12.28

Bourns, Inc. H-516-6M

DIAL COUNTING 0-15 TURNS

6.38

Precision Electronics Corporation E15-1-11

DIAL DIGITAL WITH KEY

36.41

Bourns, Inc. H-22-6A-B

DIAL SCALE 15 TURN CONCENTRIC

12.89
