Shunts, Jumpers

Shunts or Jumpers are designed to connect two pin contacts for an electrical connection that are separated by a specific distance or pitch. The types are Closed Top/Grip, Insulated, Non-Insulated, and Open Top/Grip with a pitch range from 0.050” (1.27mm) to 1.00” (25.40mm) and the number of positions ranging from 1 (1 x 1) to 48 (1 x 24) or 4 (2 x 2) to 26 (2 x 13).

---

Adam Tech MSBG-03-G

GANG SHUNT 3P 2.54MM PITCH

0.24

Amphenol ICC (FCI) 68786-102

1X2 LOW PROFILE JUMPER

0.21

Adam Tech MSC-G

SHUNT 2.54MM PITCH

0.18

Adam Tech MSA-G

SHUNT 2.54MM PITCH

0.15

Adam Tech MSBG-02-G

GANG SHUNT 2P 2.54MM PITCH

0.15

Adam Tech MSBH-G

SHUNT 2.54MM PITCH

0.15

Adam Tech MS2B-G

MINI SHUNT 2.0MM 2P GOLD

0.12

Adam Tech MS2A-G

MINI SHUNT 2.0MM 2P GOLD

0.12
