Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

Bourns, Inc. 2-4-6WEL

BALUN 20KHZ-250MHZ 1:4 6SMD GW

0

Bourns, Inc. 2-2.5-6WEL

BALUN 10KHZ-100MHZ 1:2.5 6SMD GW

0

Bourns, Inc. 2-16-6DL

BALUN 30KHZ-75MHZ 1:16 6DIP

0

Bourns, Inc. 2-13-1DL

BALUN 300KHZ-120MHZ 1:13 6DIP

0

M/A-Com Technology Solutions MABACT0067

BALUN 1MHZ-350MHZ 4:1 5SMD

0

M/A-Com Technology Solutions MABACT0066

BALUN 5MHZ-1GHZ 4:1 6SMD GW

0

M/A-Com Technology Solutions MABACT0063

BALUN 5MHZ-1GHZ 1.5:1 6SMD FLAT

0

M/A-Com Technology Solutions MABACT0062

BALUN 3MHZ-200MHZ 1:1 6SMD FLAT

0
