RF Directional Coupler

RF Directional Couplers are designed to couple a specific amount of electromagnetic power in a transmission line to a secondary line enabling the signal to be used in another circuit. The coupler types are Coupler-with Filter, Dual Band-Dual Path, and Standard with frequencies ranging from DC to 40 GHz. The coupling factor ranges from -20 dB to 49 dB with applications being AGSM, AMPS, CDMA, Cellular, DCS, DECT, E-GSM, General Purpose, GSM, LTE, Military, PCN, PCS, PDC, PHP, S-Band Radar, Telecom, W-CDMA, Wireless LAN, WLAN, and X-Band Radar.

---

AVX Corporation CP0805B1960BWTR

RF DIR COUPLER 1.93-1.99GHZ 0805

0.35

AVX Corporation CP0805B1975CWTR

RF DIR COUPLER 1.975GHZ 0805

0.35

Anaren 1P503AS

RF DIR COUPLER 1.7GHZ-2GHZ SMD

1.11

AVX Corporation DB0805A2017ASTR\500

RF DIR COUPLR 2.01-2.025GHZ 0805

0.88

AVX Corporation DB0805A2017ASTR

RF DIR COUPLR 2.01-2.025GHZ 0805

0.68

Anaren XC2100E-03S

RF DIR COUPLER 2GHZ-2.3GHZ SMD

1.64

Anaren XC1900E-03S

RF DIR COUPLER 1.7GHZ-2GHZ SMD

1.64

Anaren XC3500M-03S

RF DIR COUPLER 3.3GHZ-3.8GHZ SMD

1.56
