Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

M/A-Com Technology Solutions MABA-011028

BALUN 600MHZ-1.7GHZ 50/50 MODULE

0

M/A-Com Technology Solutions ETC4-1-2TR

BALUN 6SMD FLAT LEAD

0.83

Pulse Electronics Network CX2232NLT

BALUN 800MHZ-1.9GHZ 1:1 5SMD MOD

0

Anaren BD120170N50100AHF

BALUN 12.7-15.4GHZ 50/100 0404

0.63

Anaren BD60120N50100AHF

BALUN 5.9GHZ-11.7GHZ 50/100 0404

0.5

Johanson Technology Inc. 2500FB16A0400E

BALUN 2.3-2.69GHZ 0805 6 PC PAD

0.49

Johanson Technology Inc. 3500FB39A0050E

BALUN 3.4GHZ-3.6GHZ 50/50 1008

0

Anaren T0727J5012AHF

BALUN 700MHZ-2.7GHZ 0805

0.39
