Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

TDK Corporation TTB12G51-900-2P-T20

BALUN 174MHZ-860MHZ 50/50 4SMD

0.23

TDK Corporation ATB2012-75011-TL000

BALUN 50MHZ-1.2GHZ 75/75 0805

0.23

Johanson Technology Inc. 3700BL15B100E

BALUN 3.4GHZ-4GHZ 50/100 0805

0.26

STMicroelectronics BAL-WILC10-01D3

BALUN 2.4GHZ-2.5GHZ 50/50 OHM

0.22

Yageo BLF2012LM37R2400A

BALUN 2.4GHZ-2.5GHZ 0805

0.22

STMicroelectronics BALF-2690-02D3

BALUN 2.4GHZ-2.5GHZ 4UFBGA FCBGA

0

TDK Corporation HHM1541E1

BALUN 2.3GHZ-2.5GHZ 50/75 0805

0

Anaren B0922A21HF

IC TRANSFORMER BALUN SMD

0.19
