Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

Johanson Technology Inc. 2450BL14C050T

BALUN 2.4GHZ-2.5GHZ 50/50 0603

0

TDK Corporation HHM1562B

BALUN 5.15-5.875GHZ 50/100 0805

0

TDK Corporation HHM17144A1

BALUN 791MHZ-960MHZ 50/100 0603

0

TDK Corporation HHM17139B1

BALUN 2.4GHZ-2.5GHZ 50/50 0603

0

TDK Corporation HHM1907B1

BALUN 4.9GHZ-5.95GHZ 50/50 0402

0

PulseR HFB075100B

BALUN ADAPT 75 TO 100 OHM B PBC

928.16

Pulse Electronics Network CX2074NL

BALUN 1MHZ-500MHZ 1:4 6SMD MODUL

3.13

Pulse Electronics Network CX2147NL

BALUN 5MHZ-200MHZ 1:1 6SMD

2.49
