Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

Pulse Electronics Network CX2039LNLT

BALUN 4.5MHZ-1.5GHZ 50/50 5SMD

0

Pulse Electronics Network CX2044LNLT

BALUN 5MHZ-500MHZ 50/50 5SMD

1.58

Pulse Electronics Network CX2040LNLT

BALUN 1MHZ-500MHZ 75/75 5SMD MOD

0

Pulse Electronics Network CX2047LANLT

BALUN 500KHZ-300MHZ 1:4 6SMD MOD

0

Johanson Technology Inc. 0433BM41A0019E

BALUN 424MHZ-444MHZ 1210

0

Murata Electronics DXW21BN7511SL

BALUN 1GHZ-1.5GHZ 75/75 0805

0

Johanson Technology Inc. 2500BL14M050T

BALUN 2.3GHZ-2.7GHZ 50/50 0603

0

Anaren BD3150N50100AHF

BALUN 3.1GHZ-5GHZ 50/100 0404

0.31
