Shunts, Jumpers

Shunts or Jumpers are designed to connect two pin contacts for an electrical connection that are separated by a specific distance or pitch. The types are Closed Top/Grip, Insulated, Non-Insulated, and Open Top/Grip with a pitch range from 0.050” (1.27mm) to 1.00” (25.40mm) and the number of positions ranging from 1 (1 x 1) to 48 (1 x 24) or 4 (2 x 2) to 26 (2 x 13).

---

Amphenol ICC (FCI) 86730-001LF

MINITEK JUMPER 2MM 2POD AU BLK

0.48

Molex 0900590007

CONN SHUNT 2POS .100 TIN

0.46

Molex 0015381024

CONN SHUNT OPEN TOP .100 TIN

0.44

Molex 0015381026

CONN SHUNT CLOSED TOP .100 TIN

0.44

Harwin Inc. D3081-05

1MM SHORTING LINK GOLD

0.43

Harwin Inc. D3082-05

1MM UNINSULATED SHORTING PLUG

0.43

Samtec, Inc. SNT-100-BK-H-H

CONN SHUNT 2POS

0.42

Samtec, Inc. SNT-100-BK-H

CONN SHUNT 2POS

0.42
