Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

Wurth Electronics Inc. 748422245

BALUN 2.4GHZ-2.5GHZ 50/200 0805

0.77

Johanson Technology Inc. 0783FB15A0100E

BALUN 779MHZ-787MHZ 50/100 0805

0

Murata Electronics DXW21BN7511TL

BALUN 50MHZ-870MHZ 75/75 0805

0

Anaren B0225J7575AHF

BALUN 200MHZ-2.5GHZ 75/75 0805

0

Johanson Technology Inc. 0896FB15A0100E

BALUN 863MHZ-928MHZ 50/100 0805

0

Johanson Technology Inc. 2450FB15A050E

BALUN 2.4GHZ-2.5GHZ 50/50 0805

0

Panasonic Electronic Components EHF-FD1617

BALUN 130MHZ-500MHZ 50/200 OHM

1.04

Johanson Technology Inc. 2450BL05A0100T

BALUN 2.3GHZ-2.69GHZ 50/100 0202

0
