Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

Johanson Technology Inc. 5325BL15B050E

BALUN 5.15GHZ-5.5GHZ 50/50 0805

0.63

Johanson Technology Inc. 2450BM08B0003T

BALUN 2.4GHZ-2.5GHZ 50/50 5SMD

0

Anaren B0205F50200AHF

BALUN 200MHZ-500MHZ 50/200 1608

2

TDK Corporation HHM1517A2

BALUN 2.3GHZ-2.5GHZ 50/50 0805

0.2

M/A-Com Technology Solutions MABA-009594-CF18A0

BALUN 5MHZ-200MHZ 1:1 6SMD GW

2.18

M/A-Com Technology Solutions MABA-011029

BALUN 5MHZ-1.2GHZ 50/75 5SMD MOD

4.98

Pulse Electronics Network CX2043LNL

BALUN 1MHZ-1GHZ 1.5:1 5SMD MODUL

3.42

Yageo BLN1608LL01R2400A

BALUN 2.4GHZ-2.5GHZ 50/100 0603

0
