Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

Toko America Inc. 458DB-1012=P3

BALUN 50MHZ-400MHZ 5SMD

0.83

Anaren B0809J50ATI

BALUN 850MHZ-915MHZ 0805

1.1

Anaren B0922J7575A50HF

BALUN 950MHZ-2.15GHZ 75/75 0805

0

Johanson Technology Inc. 5400BL14B100T

BALUN 4.9GHZ-5.87GHZ 50/100 0603

0

TDK Corporation ATB3225-75011CT-T001

BALUN 5MHZ-200MHZ 1:1 1210

0.95

M/A-Com Technology Solutions MABA-011085

BALUN 5 - 1225 MHZ 1:1

0

Pulse Electronics Network CX2047LNLT

BALUN 500KHZ-300MHZ 50/50 5SMD

2.9

Pulse Electronics Network CX2043LNLT

BALUN 1MHZ-1GHZ 1.5:1 5SMD MODUL

0
