Balun

A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.

---

TDK Corporation DEA102500LT-9052A1

BALUN 2.3GHZ-2.5GHZ 0402

0

TDK Corporation HHM1522A7

BALUN 824MHZ-894MHZ 50/50 0805

0.2

TDK Corporation HHM17152A1

BALUN 698MHZ-894MHZ 50/100 0603

0.69

Anaren BD2425NNRF

BALUN 2.4GHZ-2.525GHZ 0404

0.66

TDK Corporation HHM1524B4

BALUN 824MHZ-894MHZ 50/150 0805

0.2

Johanson Technology Inc. 2450BL14C200T

BALUN 2.4GHZ-2.5GHZ 50/200 0603

0

Johanson Technology Inc. 2345FB39A0050E

BALUN 2.3GHZ-2.39GHZ 50/50 1008

1.49

TDK Corporation HHM1908A2

MULTILYER BALUN FOR 4900 - 5950M

0
